RACCORDI DI LUCE/JOY

Luminaire suitable for installation on normally flammable surfaces

Low-voltage luminaire with remote transformer.

5690

3.40 cm

Select the finish and type of lamps to find out the corresponding code

	.01	White
	.02	Black
	.33	Brushed steel
	.34	Corten painted

/W	1.5W	180lm	4000K	CRI>90
/WW	1.5W	162lm	3000K	CRI>90
/XW	1.5W	153lm	2700K	CRI>90

Technical features

Electrification:	500mA
Light:	live
IP grade:	65
Dimensions:	3.40 cm
Net weight:	0.20 kg
Materials:	stainless steel

Documentation

Data sheet Assembly instructions 2D Model 3D Model

IP65 direct light ceiling or floor lamp with integrated 500mA LED source, stainless steel and aluminum structure with reinforced anodization for outdoor use.
Available in the catalog with 2700K, 3000K and 4000K white light with CRI>90.
The small size and type of light are ideal for illuminating passages, corridors or special outdoor environments, gardens or for creating light effects on house facades or illuminating pathways under porches or verandas.
Its operation requires the use of a driver to be placed remotely and ordered separately.
