KROSS

Luminaire suitable for installation on normally flammable surfaces

Low-voltage luminaire with remote transformer.

6361

Select the finish and type of lamps to find out the corresponding code

.33

Brushed steel

/B	1.5W	-	Blue Led	CRI>90
/W	1.5W	221lm	4000K	CRI>90
/WW	1.5W	210lm	3000K	CRI>90
/XW	1.5W	199lm	2700K	CRI>90

Technical features

Electrification:	350mA
Light:	radial
IP grade:	67
Net weight:	0.10 kg
Round recessed hole:	3.20 cm
Materials:	aISI 316L stainless steel/aluminum

Documentation

Data sheet Assembly instructions

IP67 walkable recessed radial spotlight with integrated 500mA LED source, AISI 316L stainless steel flange, aluminum heat sink and 30cm neoprene cable.
The spotlight is available in the catalog with integrated power LED in 2700K, 3000K and 4000K white light with CRI>90.
The spotlight can be installed on plasterboard with special accessory provided or in bricks with dedicated formwork to be ordered separately.
Operation requires a special driver to be ordered separately. Dimmable power supplies with PUSH, 1...10V, TRIAC or DALI control are also available.
