WANDA - A4536

WANDA

Apparecchio adatto ad essere installato su superfici normalmente infiammabili Apparecchio a bassa tensione con trasformatore remoto. IP67 IK10 Alimentatore escluso Apparecchio riparabile CRI > 90 Indice di resa cromatica

A4536

Seleziona la finitura e la tipologia di lampade per conoscere il codice corrispondente

.33

Acciaio satinato
RGB - 46.4566944 inch - RGB CRI>90
/W 1.5W 7.0866144 inch 184lm 4000K CRI>90
/WW 1.5W 7.0866144 inch 165lm 3000K CRI>90
/XW 1.5W 7.0866144 inch 156lm 2700K CRI>90
RGB 1.5W 7.0866144 inch - RGB CRI>90
/W 3W 11.0236224 inch 368lm 4000K CRI>90
/WW 3W 11.0236224 inch 330lm 3000K CRI>90
/XW 3W 11.0236224 inch 312lm 2700K CRI>90
RGB 3W 11.0236224 inch - RGB CRI>90
/W 4.5W 14.9606304 inch 552lm 4000K CRI>90
/WW 4.5W 14.9606304 inch 495lm 3000K CRI>90
/XW 4.5W 14.9606304 inch 468lm 2700K CRI>90
RGB 4.5W 14.9606304 inch - RGB CRI>90
/W 6W 18.8976384 inch 736lm 4000K CRI>90
/WW 6W 18.8976384 inch 660lm 3000K CRI>90
/XW 6W 18.8976384 inch 624lm 2700K CRI>90
RGB 6W 18.8976384 inch - RGB CRI>90
/W 7.5W 22.8346464 inch 920lm 4000K CRI>90
/WW 7.5W 22.8346464 inch 825lm 3000K CRI>90
/XW 7.5W 22.8346464 inch 780lm 2700K CRI>90
/W 9W 26.7716544 inch 1104lm 4000K CRI>90
/WW 9W 26.7716544 inch 990lm 3000K CRI>90
/XW 9W 26.7716544 inch 936lm 2700K CRI>90
RGB 9W 26.7716544 inch - RGB CRI>90
/W 10.5W 30.7086624 inch 1288lm 4000K CRI>90
/WW 10.5W 30.7086624 inch 1155lm 3000K CRI>90
/XW 10.5W 30.7086624 inch 1092lm 2700K CRI>90
RGB 10.5W 30.7086624 inch - RGB CRI>90
/W 12W 34.6456704 inch 1472lm 4000K CRI>90
/WW 12W 34.6456704 inch 1320lm 3000K CRI>90
/XW 12W 34.6456704 inch 1248lm 2700K CRI>90
RGB 12W 34.6456704 inch - RGB -
/W 13.5W 38.5826784 inch 1656lm 4000K CRI>90
/WW 13.5W 38.5826784 inch 1485lm 3000K CRI>90
/XW 13.5W 38.5826784 inch 1404lm 2700K CRI>90
RGB 13.5W 38.5826784 inch - RGB -
/W 15W 42.5196864 inch 1840lm 4000K CRI>90
/WW 15W 42.5196864 inch 1650lm 3000K CRI>90
/XW 15W 42.5196864 inch 1560lm 2700K CRI>90
RGB 15W 42.5196864 inch - RGB CRI>90
/W 16.5W 46.4566944 inch 2024lm 4000K CRI>90
/WW 16.5W 46.4566944 inch 1815lm 3000K CRI>90
/XW 16.5W 46.4566944 inch 1716lm 2700K CRI>90
/W 18W 50.3937024 inch 2208lm 4000K CRI>90
/WW 18W 50.3937024 inch 1980lm 3000K CRI>90
/XW 18W 50.3937024 inch 1872lm 2700K CRI>90
RGB 18W 50.3937024 inch - RGB CRI>90
/W 19.5W 54.3307104 inch 2392lm 4000K CRI>90
/WW 19.5W 54.3307104 inch 2145lm 3000K CRI>90
/XW 19.5W 54.3307104 inch 2028lm 2700K CRI>90
RGB 19.5W 54.3307104 inch - RGB CRI>90
/W 21W 58.2677184 inch 2576lm 4000K CRI>90
/WW 21W 58.2677184 inch 2310lm 3000K CRI>90
/XW 21W 58.2677184 inch 2184lm 2700K CRI>90
RGB 21W 58.2677184 inch - RGB CRI>90
/W 22.5W 62.2047264 inch 2760lm 4000K CRI>90
/WW 22.5W 62.2047264 inch 2475lm 3000K CRI>90
/XW 22.5W 62.2047264 inch 2340lm 2700K CRI>90
RGB 22.5W 62.2047264 inch - RGB CRI>90
/W 24W 66.1417344 inch 2944lm 4000K CRI>90
/WW 24W 66.1417344 inch 2640lm 3000K CRI>90
/XW 24W 66.1417344 inch 2496lm 2700K CRI>90
RGB 24W 66.1417344 inch - RGB CRI>90
/W 25.5W 70.0787424 inch 3128lm 4000K CRI>90
/WW 25.5W 70.0787424 inch 2805lm 3000K CRI>90
/XW 25.5W 70.0787424 inch 2652lm 2700K CRI>90
RGB 25.5W 70.0787424 inch - RGB CRI>90
/W 27W 74.0157504 inch 3312lm 4000K CRI>90
/WW 27W 74.0157504 inch 2970lm 3000K CRI>90
/XW 27W 74.0157504 inch 2808lm 2700K CRI>90
RGB 27W 74.0157504 inch - RGB CRI>90
/W 28.5W 77.9527584 inch 3496lm 4000K CRI>90
/WW 28.5W 77.9527584 inch 3135lm 3000K CRI>90
/XW 28.5W 77.9527584 inch 2964lm 2700K CRI>90
RGB 28.5W 77.9527584 inch - RGB CRI>90
/W 30W 81.8897664 inch 3680lm 4000K CRI>90
/WW 30W 81.8897664 inch 3300lm 3000K CRI>90
/XW 30W 81.8897664 inch 3120lm 2700K CRI>90
RGB 30W 81.8897664 inch - RGB CRI>90
/W 31.5W 85.8267744 inch 3864lm 4000K CRI>90
/WW 31.5W 85.8267744 inch 3465lm 3000K CRI>90
/XW 31.5W 85.8267744 inch 3276lm 2700K CRI>90
RGB 31.5W 85.8267744 inch - RGB CRI>90
/W 33W 89.7637824 inch 4048lm 4000K CRI>90
/WW 33W 89.7637824 inch 3630lm 3000K CRI>90
/XW 33W 89.7637824 inch 3432lm 2700K CRI>90
RGB 33W 89.7637824 inch - RGB CRI>90
/W 34.5W 93.7007904 inch 4232lm 4000K CRI>90
/WW 34.5W 93.7007904 inch 3795lm 3000K CRI>90
/XW 34.5W 93.7007904 inch 3588lm 2700K CRI>90
RGB 34.5W 93.7007904 inch - RGB CRI>90
/W 36W 97.6377984 inch 4416lm 4000K CRI>90
/WW 36W 97.6377984 inch 3960lm 3000K CRI>90
/XW 36W 97.6377984 inch 3744lm 2700K CRI>90
RGB 36W 97.6377984 inch - RGB CRI>90
/W 37.5W 101.5748064 inch 4600lm 4000K CRI>90
/WW 37.5W 101.5748064 inch 4125lm 3000K CRI>90
/XW 37.5W 101.5748064 inch 3900lm 2700K CRI>90
RGB 37.5W 101.5748064 inch - RGB CRI>90
/W 39W 105.5118144 inch 4784lm 4000K CRI>90
/WW 39W 105.5118144 inch 4290lm 3000K CRI>90
/XW 39W 105.5118144 inch 4056lm 2700K CRI>90
RGB 39W 105.5118144 inch - RGB CRI>90
/W 40.5W 109.4488224 inch 4968lm 4000K CRI>90
/WW 40.5W 109.4488224 inch 4455lm 3000K CRI>90
/XW 40.5W 109.4488224 inch 4212lm 2700K CRI>90
RGB 40.5W 109.4488224 inch - RGB CRI>90
/W 42W 113.3858304 inch 5152lm 4000K CRI>90
/WW 42W 113.3858304 inch 4620lm 3000K CRI>90
/XW 42W 113.3858304 inch 4368lm 2700K CRI>90
RGB 42W 113.3858304 inch - RGB CRI>90
/W 43.5W 117.3228384 inch 5336lm 4000K CRI>90
/WW 43.5W 117.3228384 inch 4785lm 3000K CRI>90
/XW 43.5W 117.3228384 inch 4524lm 2700K CRI>90
RGB 43.5W 117.3228384 inch - RGB CRI>90

Caratteristiche tecniche

Luce: diffusa
Grado IP: 67
Peso netto: 2.38 lb
Materiali: acciaio INOX AISI 316L/metacrilato

Documentazione

Scheda tecnica

Accessori correlati

0155

0155

0156

0156

0157

0157

0160

0160

0161/100

0161/100

0110/DIM

0110/DIM

0717/DIM60

0717/DIM60

0717/DIM60/V

0717/DIM60/V

0717/DIM100

0717/DIM100

0115/EM

0115/EM

0033/IP

0033/IP

0034/IP

0034/IP

0035/IP

0035/IP

0717/DIM150

0717/DIM150

0164

0164

0167

0167

0163

0163

0165

0165

0166

0166
